Imagine powering your home with abundant energy while lowering or eliminating your grid reliance. You can already do it with solar energy solutions. However, can this energy keep your lights on 24/7? Yes, but you need ample storage. A tailored solar energy storage system can power your appliances even on long winter nights.
Today, you’ll learn how solar energy is stored, the main types of solar batteries, and which one best suits you. Whether you’re a homeowner curious about eco-friendly power or a businessman looking for clean commercial energy solutions, this article is for you! We’ll clear up any confusion and answer all your burning questions.
Solar panels harness the sun’s rays and turn them into usable electricity through the photovoltaic effect. Sunlight is made up of countless particles of energy called photons. When these particles hit a silicon atom inside the solar power cell, they inject energy. This energy bump excites an electron in the atom, breaking it free from its orbit and setting it in motion.
The freed electron, eager to find a new home, is guided by the clever design of the PV cell. An internal electric field acts as a gentle push, directing the electron toward the negative (n-type) side of the cell, from where it flows out into the circuit.
As more sunlight hits the panel, more electrons are set in motion, forced to flow in the same direction by the electric field. This movement of electrons generates a Direct Current (DC). DC electricity can charge batteries and power DC devices, but most home appliances run on Alternating Current (AC), so an inverter has to convert it first.
While solar panels themselves don’t store energy, they can team up with batteries to create a solar energy storage system. These batteries capture excess DC electricity produced during sunny periods and store it for later use, like at night or on cloudy days when sunlight is limited. This way, you can maximize the use of your solar-generated power.
In the perfect scenario, the electricity generated by the panel perfectly meets your current needs, so it just flows from the panels to the inverter and onward to your appliances.
However, we don’t live in a perfect world. Even in summer, there are still at least 7-9 hours without a Sun. That’s why solar panel owners still need to think about how to store solar power or get discounts on grid electricity.
You can use a solar energy storage system on cloudy days or at night to power your appliances. It acts as a big power bank, collecting excessive electricity. However, you will need the inverter to convert DC electricity to the AC for your appliance.
Additionally, you can benefit from using hybrid solar power storage. These systems combine elements of both on-grid and off-grid systems, offering more flexibility and resilience than either one alone. They have a highly customizable inverter, which you can program according to your preference:
By default, hybrid solar storage solutions prioritize self-consumption by using solar power to fill batteries and only send excesses to the grid. However, you can change those settings to suit your habits.
Batteries don’t directly store electricity. They use chemical reactions to reserve energy in their solar energy storage. In most systems, a separate inverter transforms DC from solar panels to AC to power your home appliances. Some systems have an inverter integrated into batteries.
Off-grid systems use a charge controller, and modern lithium batteries have a built-in battery management system (BMS) that regulates the incoming current to prevent overcharging. In the long run, overcharging can damage the batteries and shorten their lifespan. That’s why you should look for more resistant options for storing solar energy. It may seem more costly at first, but eventually, it can save you thousands of dollars by increasing the batteries’ lifespan.
Once regulated, the electricity flows into the solar energy storage, a.k.a solar battery. Inside each battery, energy is stored through electrochemical processes involving the electrodes (positive and negative) and the electrolyte. In lead-acid batteries, the lead plates react with a sulfuric acid electrolyte, while in lithium batteries, lithium ions move between the electrodes. The specific chemical reactions in a solar energy storage system depend on the battery type.
Imagine the battery as a container where charging pushes the materials inside into a higher-energy state: the lead plates change their chemical composition, or lithium ions move from the positive electrode to the negative one. Discharging reverses the process, returning the materials to their original state and releasing the stored energy as electricity.
These chemical reactions store the electrical energy from the DC. There are no solar panels that store energy since they don’t have a place to store the electrodes and electrolytes in the long run. You need batteries to reserve excessive power.
Solar systems primarily use two types of batteries to store energy: lithium-ion (Li-ion) and lead-acid batteries. Today, lithium-ion batteries, especially lithium iron phosphate (LFP) models, are the standard for home solar storage, while lead-acid batteries are mostly used in small off-grid setups. Each solar energy storage system has its advantages and disadvantages, for instance:
It’s a lightweight and efficient option for those who want to store energy collected by solar cells.
Unlike lead-acid batteries, which rely on lead plates submerged in acid, lithium-ion solar energy storage systems use lithium ions to move between electrodes. The cathode (positive electrode) and anode (negative electrode) are made from specific materials that allow lithium ions to shuttle back and forth during charging and discharging.
Most modern home batteries, including the Tesla Powerwall 3, Enphase IQ Battery, and FranklinWH aPower, use lithium iron phosphate (LFP) chemistry. It is safer, less prone to overheating, and longer-lasting than the older nickel-based lithium-ion cells.
They also require minimal maintenance compared to lead-acid batteries, which need occasional watering. With Li-ion solar energy storage options, you don’t need to worry about electrolyte levels or topping them up with water.
However, a Li-ion solar energy storage system costs more than lead-acid options. Li-ion batteries are also susceptible to temperature. They perform best in moderate temperatures, but extreme heat or cold can reduce their efficiency and lifespan.
These batteries are a more affordable option. Lead-acid energy storage has been around for over 160 years. They rely on a well-understood chemical reaction between lead plates (electrodes) submerged in a sulfuric acid electrolyte solution.
During charging, an external source (like your solar panels) pushes electrons through the circuit, converting lead sulfate on the plates back to lead (anode) and lead dioxide (cathode). When discharging, the electrons flow in the opposite direction of the solar energy storage system, reversing the chemical reaction and generating electricity.
However, these solar energy storage solutions are losing their efficiency faster than Li-ion batteries. That’s why most lead-acid solar batteries last only 5–7 years, and their warranties are usually even shorter. Over that time, their usable capacity declines noticeably. Thus, they have become less and less popular methods of storing energy from solar panels and are now mostly used in small off-grid systems.
They also require regular care, such as checking and refilling water levels (flooded lead-acid) to prevent damage. You should also remember that lead is a toxic metal, so dead batteries must be properly recycled. Fortunately, lead-acid batteries are among the most recycled products in the US, and most retailers that sell them accept them back.
Solar panels are a fantastic way to tap into clean, renewable energy from the sun. While they can’t store energy directly, battery storage systems provide a solution. They use clever chemistry to hold onto the electricity generated by your panels, allowing you to utilize it even at night.
You can maximize the amount of usable electricity by strategically placing your panels and using technologies like microinverters and adding battery storage.
Whether your goal is self-reliance, backup power during outages, or reducing your dependence on the grid, understanding how a solar energy storage system works can empower you to make even more informed decisions for your home or business.
Consulting with a qualified solar professional can help you design a system that allows you to harness the sun’s energy and enjoy the benefits of clean, renewable power. We at Resident Solar Power can help you find a local installer team that incorporates the best decisions for your needs.
Panels capture the sun’s energy through a process called the photovoltaic effect. Sunlight is made up of countless photons. When a photon hits a silicon atom in the PV cell, it injects its energy, breaking an electron free and setting it in motion. The solar cell is designed with an internal electric field that directs the loose electron toward the negative (n-type) side of the cell, creating an electric current known as Direct Current (DC).
Solar panels themselves cannot directly store electricity. They convert sunlight into usable DC electricity, but you need a battery storage system to save this energy. In DC-coupled systems, electricity from the panels goes to the battery through a hybrid inverter or charge controller. In systems with microinverters mounted on each panel, the power is converted to AC first, so the battery is AC-coupled and needs its own inverter, unless it has one built in.
To optimize sunlight exposure, locate panels in areas with unobstructed sunlight throughout the day. Slightly tilt panels to ensure that the tilting angle is close to the location’s latitude. Regularly clean them from dust, dirt, and bird droppings.
No, they can’t do it. Panels are excellent at converting sunlight into electricity, but they lack the internal mechanisms to hold that electrical energy for later use. You need solar energy storage systems (batteries and an inverter) to store the electricity and convert it to AC for your appliances.
